ASI Roval Accessories

Hand sanitizer dispenser stand has a sleek and durable type 304 stainless steel hand sanitizer dispenser stand is free standing for convenient placement where needed and allows for easy mobility. The 11 gauge stand is designed with rounded edges for user safety, with an 18 gauge mounting plate and tube. This unit works with 20364 and 20365 models for american specialties.

Dimensions:

Roval Automatic Deck Mounted Soap Dispenser, 20333 Constructed of polished type 304 stainless steel on exposed surfaces with battery-operated, hands-free sensor. LEDs indicate function, battery condition and soap supply level on face front. Translucent tank holds 54 oz. (1600 ml) of liquid soap

Roval Automatic Soap Dispenser, 20364 Hands-free, battery-operated soap dispenser. Dispensing cycles adjustable with tamper proof magnetic key. Seamless drawn type 304 stainless steel cover. Translucent removable internal tank for easy-to-view soap level. LED indicates adjustment and operation. Bulk fill with a 34 oz capacity. Overall Size 5 1/2" W x 10 7/8" H x 4" D projection

Roval Automatic Foam Soap or Foam Hand Sanitizer Dispenser, 20365 A foam drop is dispensed out of the nozzle on unit bottom each time its battery-operated sensor is activated. Capacity: 34 oz. (1000 ml) of liquid foaming soaps within a wide range of viscosity. Overall Size 5 1/2” x 10 7/8” x 4” (140 x 276 x 102 mm) projection. Soap Requirements: Proper usage of this dispenser requires, that only soap/lotion/foaming hand sanitizer within the following range for viscosity and pH may be used.

ASI Roval cast iron hand dryers offers many features, Quick Dry (Under 25 Secs), No Touch (Energy Efficient), Universal Voltage (100-240 VAC & 50/60 Hz), Only Available in White, Cover made from ¼” Thick Heavy Duty Cast Iron, ADA Compliant, Durable yet Modern Design. Dimensions are 15-3⁄32"W x 11-7⁄32"H x 3-15⁄16"D (383 x 285 x 100 mm).

Same as 20030 but with flange for semi-recessing. Holds two rolls up to 5 1/4" diameter (double roll capacity 3600 sheets). Top roll automatically drops in place when bottom roll is used up. Type 304 satin finish stainless steel cabinet and mechanism. Theft-resistant spindles with integral plated steel endpins. Overall Size 6 1/16" W x 12 1/8" H x 6 1/2" D

Heavy-duty 9/64" staked piano hinge adds to the robust construction. Drawn one piece seamless door of 22 gauge type 304 stainless steel with a satin finish. 1 gal. (3.7 L) waste capacity. wall opening 11-3/8"tall x 9-5/8"wide x 4"deep.

Roval Surface Mounted Vertical Soap Dispenser, 20363 Same as 20364 but with push button. Valve operation complies with ADAAG, needing no more than 5 lbs of pressure to actuate. Gently radiused edge complements the curves of the ASI Roval Collection. Bulk fill with a 57 oz capacity. Overall Size 5 1/2” x 10 7/8” x 4” projection.

Fabricated of 18 gauge type 304 stainless steel, the 6” wide shelf has a ¾” (19mm) gently radiused edge that uniquely complements the curves of the ASI Roval™ Collection. Choice of sizes. offering 12",18", 24", 30" 36" 48" 60" 72".

Roval Surface Mount Waste Receptacle 20826 Receptacle front and sides fabricated of 20 gauge type 304 stainless steel with satin finish. Capacity 11 gal. (42 L). Same as 20826 but with closed top, spring-loaded door. Capacity 12.8 gal. (48.8 L). Overall size 15-1/8"x23"x8-1/2"

Dispenses 250 seat covers. Fabricated of 20 gauge type 304 stainless steel with a satin finish.

Roval Surface Mount Sanitary Waste Receptacle, 20852 Lid and cabinet are each drawn one piece construction. Lid is secured to the cabinet with a heavy-duty 9/64" multi-staked concealed piano hinge

Roval Stainless Steel Mirror with Integral Shelf 20655 The gently radiused edges provide added strength and complement the curves of the ASI Roval™ Collection. Mirror frame and 6” wide curved edge shelf are fabricated of 18 gauge type 304 stainless steel with satin finish. Mirror frame has polished seamless mitered corners. 0.25” (6.4 mm) thick plate glass mirror. Warranted for 15 years against silver spoilage. Choice of sizes. or Same as 20655 but with tempered glass

Roval Stainless Steel Mirror 20650 The gently radiused edges uniquely complement the curves of the ASI Roval™ Collection. Frame fabricated of 18 gauge type 304 stainless steel with satin finish and polished seamless mitered corners. 1/4" thick plate glass mirror. Warranted for 15 years against silver spoilage. Choice of sizes or Same as 20650 but with tempered glass.

Roval Semi Recessed Removable Waste Receptacle. 20458 Easy maintenance — removable stainless steel waste receptacle locks into cabinet with a tumbler lock for security. Capacity 11.2 gal. (42.6 L). Fabricated of 20 gauge type 304 stainless steel with satin finish. Wall Opening: 15 5/8" W x 26 5/16" H x 4" D

Roval Recessed Paper Towel Dispenser, 20452 Dispenses 600 C-fold or 800 multi-fold paper towels. Door fabricated of 18 gauge type 304 drawn one piece stainless steel with satin finish. Door secured with 3/16" staked piano hinge and flush tumbler lock. Wall Opening: 11 3/16" W x 26 1/4" H x 4" D

Roval Recessed Hand Dryer, 20199

This high performing hand dryer, with a drying time of less than 15 seconds, has a cover made of 18 gauge stainless steel and uniquely complements the Roval™ Collection with its bowed face and gently radiused edges. 5-year warranty.

FEATURES:

• Quick drying — less than 15 seconds
• Operates automatically using infrared sensor
• Auto-resetting thermostat

Heavy-duty 9/64" staked piano hinge adds to the robust construction. Drawn one piece seamless door of 22 gauge type 304 stainless steel with a satin finish. 1 gal. (3.7 L) waste capacity. wall opening 11-3/8"tall x 9-5/8"wide x 4"deep. Same as 20470 but mounts through partitions up to 1 1/4" thick. Expandable steel waste can ensures a perfect fit for thicker partitions. This for 2 stalls with a common partition divider.

Roval Paper Towel Dispenser & Removable Waste Receptacle. Dispenses 600 C-fold or 800 multi-fold paper towels. 14.8 gal. (56 L) removable waste receptacle. Door made of 18 gauge type 304 stainless steel with a heavy-duty 3/16" staked piano hinge. Wall Opening: 15 3/4" W x 54 1/2" H x 4" D

Roval Paper Towel Dispenser & Removable Waste Receptacle. Dispenses 350 C-fold, 475 multi-fold paper towels. 2.96 gal. (11.2 L) removable stainless steel waste receptacle with a tumbler lock. 22 gauge type 304 stainless steel door in a satin finish with a flush lock and a heavy-duty 3/16" staked piano hinge on door. Wall Opening: 12 3/4" W x 26 1/2" H x 4 1/4" D

Roval Paper Towel Dispenser, 20210 Dispenses 400 C-fold or 525 multi-fold paper towels. Fabricated of 22 gauge type 304 stainless steel with satin finish. Fitted with tumbler lock and heavy-duty stainless steel staked piano hinge.
ASI spec sheet

Roval Dual Sanitary Napkin & Tampon Dispenser Dispenses 31 napkins and 22 tampons. Door made of 18 gauge type 304 satin finish stainless steel, with two flush tumbler locks. Universal coin mechanism is convertible for 25 cents, 50 cents or FREE (no coin) operation. Coin boxes have different lock and key than doors. Wall Opening: 15 5/8" W x 25 7/8" H x 4" D

Roval Automatic Roll Towel Dispenser & Waste Receptacle Fabricated of 18 gauge type 304 stainless steel. 17.8 gal. (67.2 L) removable waste receptacle. Wall Opening: 15 13/16” x 54 11/16” x 10”

Available in Recessed, Semi Recessed and Surface mount. Fabricated of 22 gauge stainless steel with satin finish. Wall Opening: 15 3/4” x 26” x 10” Power Source can be hard wired is (AC) or Battery Operated (A) Battery not supplied, 4-D Batteries. Automatic Mechanism. Unit automatically dispense one predetermined length at a time when hands are placed in the sensor zone. The owner can determine the length of sheets.

Roval Automatic Roll Paper Towel & Waste Receptacle with Smaller waste receptacle, 13.5 gal. (51.1 L), allows installation according to ADAAG. Internal shelf is ideal for paper towel storage. Wall Opening: 15 13/16” x 54 11/16” x 10” Power Source can be hard wired is (AC) or Battery Operated (A) Battery not supplied, 4-D Batteries.
