Floor Mounted Door Stops / Holders

Automatic Floor Type Holder and Stop

Cast brass construction, and then chrome plated. Measures 3-11/16" high by 3" wide with a 1-15/16" projection. The strike is 1-3/16" high. Spring loaded brass roller, rolls over the the strike to lock the door in the open position. To release, just give the door a tug.

The Ives Universal Dome Floor Stop FS439 is constructed of cast zinc or stainless steel, depending on the finish.   The stop measures 1-1/2" high, with a base height of 1/4" and base diameter of 1-7/8".   The pad has a height of 1-1/8" from the floor.

Ives Part Number FS439

The Ives Decorative Floor Stop FS410 is constructed of cast brass.   It measures 1-1/2" high with a 1-1/4" diameter.  Manufacture part FS410 x Finish.

Ives Dome Door Stop 1" Height FS436

Features:

• For doors without threshold.
• Heavy-Duty Cast Dome Stops constructed of brass, bronze or aluminum.
• Gray, non-marring rubber bumper.

Overall hgt 1"
Base Hgt 3/16"
Base Diameter 1-3/4" x 2" Oval

Ives Dome Door Stop 1-3/8" FS438

Features:

• For doors with threshold or undercut doors.
• Heavy-Duty Cast Dome Stops constructed of brass, bronze or aluminum.
• Gray, non-marring rubber bumper.

Overall hgt 1-3/8"
Base Hgt 9/16"
Base Diameter 1-3/4" x 2" Oval

Dome Door Stop 1-5/8" Height 521

Forged brass construction with a gray rubber bumper. 1-3/4" diameter x 1-5/8" High x 1/4" Base thickness, US26D-Brushed Chrome finish only.
Supplied with wood screws and machine screws with anchors

Ives Floor Mounted Door Holder FS446

Features:

• Manual type floor holder ideal for interior or exterior use.
• Cast brass or aluminum construction.
• Accommodates door undercut up to 2-1/2".
• Non-marring rubber tip.
• Unit functions as a stop but serves as a Hold-Open device when hook is manually engaged instrike. Unit requires manual disengagement to release Hold-Open.
• Packed with expansion shield and lead shield.

Overall Height 3-3/4"
Height to Stop Center Line 2-5/8"
Diameter 2-1/2"

Ives Floor Mounted Door Holder FS40

This floor mounted door holder has been around since the 1960's. It used to go by the name Glynn Johnson GJF40A or F40A, and was brought over to the H.B. Ives line in the 1990's. Many schools and hospitals have this door holder in use today. It features: Automatic door holders ideal for heavy-traffic situations that require a simple, fool-proof, Hold-Open device. Forged from brass. Unit is activated automatically when door is opened. A firm pull on door releases the mechanism. Strikes accommodate different door to floor clearances. Model numbers are determined by strike/door-to-floor clearances. Holder position on door is adjustable.

Door to Floor Clearance 1/2" or less
Holder Dimensions 3" Wide x 3-11/16" High

Ives Floor Mounted Door Holder FS41

Features:
• Automatic door holders ideal for heavy-traffic situations that require a simple,
fool-proof, Hold-Open device.
• Forged from brass.
• Unit is activated automatically when door is opened. A firm pull on door releases
the mechanism.
• Strikes accommodate different door to floor clearances.
• Model numbers are determined by strike/door-to-floor clearances.
• Holder position on door is adjustable.

Door to Floor Clearance 9/16" to 1-1/16"
Holder Dimensions 3" Wide x 3-11/16" High

Ives Floor Mounted Door Holder FS42

Features:
• Automatic door holders ideal for heavy-traffic situations that require a simple,
fool-proof, Hold-Open device.
• Forged from brass.
• Unit is activated automatically when door is opened. A firm pull on door releases
the mechanism.
• Strikes accommodate different door to floor clearances.
• Model numbers are determined by strike/door-to-floor clearances.
• Holder position on door is adjustable.

Door to Floor Clearance 1-1/8" to 1-9/16"
Holder Dimensions 3" Wide x 3-11/16" High

Ives Floor Mounted Door Holder FS43

Features:
• Automatic door holders ideal for heavy-traffic situations that require a simple,
fool-proof, Hold-Open device.
• Forged from brass.
• Unit is activated automatically when door is opened. A firm pull on door releases
the mechanism.
• Strikes accommodate different door to floor clearances.
• Model numbers are determined by strike/door-to-floor clearances.
• Holder position on door is adjustable.

Door to Floor Clearance 1-5/8" to 2-11/16"
Holder Dimensions 3" Wide x 3-11/16" High

Floor Mounted Door Stop Heavy Duty 540

This Floor Mounted Door Stop is a personal favorite. It is extremely heavy duty, and is ideal for areas of high vandalism. Includes the 4-1/2" lag bolt & lag shield. The rubber base is 3" in diameter and is 2-5/8" high.  Uses a 3/4" diameter hole for the lag sheild.

Floor Mounted Door Holder Heavy Duty 541

3" Diameter
3" Height
Includes the 4-1/2" lag bolt & lag shield.

Floor Mounted Door Stop 535

Cast Brass or Bronze construction
2-1/2" diameter base x 3-1/8" high
Fasteners included

Floor Mounted Door Stop and Holder
Manual type door holder ideal for interioror exterior use
Cast Bronze Construction
Strike features hinged hook which engages the holder
Accommodates door undercut up to 2-1/2"

Floor Mounted Door Stop FS18

Features:

• Security Door Stops designed for use in high vandalism areas.
• Molded from flame resistant, resilient material around a heavy-duty stud.
• Once grouted in concrete, leaves no exposed fasteners to be tampered with or removed.
• Ideal for jail or security cell areas where floor mounted stops are required.
• FS18L also ideal for concrete wall applications.
• Finish: Black, 2" Diameter

FS18S 1-1/2" Height
FS18L 3" Height

Ives Floor Mounted Door Stop FS434

Features:

• Burnished wrought steel.
• Soft, resilient gray rubber.
• For undercut doors up to 1-1/2".
• Packed with screws and plastic anchors.

Overall height 2-5/8"
Base size 1-1/2" W x 2-3/4" L

Ives Floor Mounted Door Stop FS434 Rubber Only

Replacement rubber shoe for the FS434.  Rubber measures 2-1/4" high by 1-7/16" wide by 5/8" thick.

Ives Part # 09-318

Ives Floor Mounted Door Stop FS442

This Floor Mounted Door Stop used to go by the name Glynn Johnson GJFB19 or FB19. When Ingersoll Rand purchased H. B. Ives in the 1990's they brought it over under the Ives Floor Mounted Door Stop FS442. Features: Designed to blend well with all types of construction and provide a minimum of hindrance to cleaning efforts. Accommodates door undercut up to 2". Heavy-Duty cast brass or aluminum construction. Non-marring rubber bumper. This door stop has an overall height 2-7/8". Mounted shield and screws included.

Floor Mounted Door Stop FS444

This door stop has been around a long time. We have been selling it for the past 35 years, and it is one of our best sellers year in and year out.

Features: Ideal for interior or exterior use. Cast brass construction. Accommodates door undercut up to 2-1/2". Non-marring rubber tip. Packed with expansion shield and lead shield. This Floor Mounted Door Stop is 3" high, and the base has a 2-1/2" diameter.

Magnet Door Stop

Hands-free magnetic door stop/holder. All you need to do is open the door and a strong maget will keep it open until you close it. Mounts horizontally or vertically. Includes fasteners plus 1 concrete and 3 hollow wall anchors.

Not for use on doors with spring hinges or door closers.
