Latches

Truth 16.52 Sash Lock. A very common sash lock that tends to fail because the plastic slide breaks due to incorrect installation at the window manufacturer or being forced when there is a obstruction in the window opening. The new replacement model has a thicker plastic slide. Because the slide is thicker, the keeper, part # Wi41268 and Wi41269 might have to be shimmed with small washers.

Common numbers found on this sash lock are 21328 and 45189

Non handed (can be used on right or left hand windows).

Truth Nylon Tie Bar Guide 45145

This nylon guide is used when you have multiple sash locks on your window.  Inside the window, or sometimes on the surface these  nylon guides keep the connecting rods in place, so you only have to actuate one lock to lock multiple locks.

Truth Nylon Tie Bar Guide 45141

This nylon guide is used when you have multiple sash locks on your window.  Inside the window, or sometimes on the surface these  nylon guides keep the connecting rods in place, so you only have to actuate one lock to lock multiple locks.

Truth Nylon Tie Bar Guide 41157

This nylon guide is used when you have multiple sash locks on your window.  Inside the window, or sometimes on the surface these  nylon guides keep the connecting rods in place, so you only have to actuate one lock to lock multiple locks.

Truth 24.33 Sash Lock

The Truth 24.33 Sash Lock has a hole spacing of 3-13/16" and the locking lug projects 1-5/8"

Truth 24.31 Sash Lock

Truth 24.31 casement window sash lock.  The hole spacing is 3-13/16" and the "Fork" projects out  1-7/8".   Housing is made of die cast metal that is then powder coated.

Truth Part # 24.31.xx.004

Truth 24.30 Sash Lock

The Truth 24.30 Sash Lock has a hole spacing of 3-13/16" and the locking lug projects 1-3/8"

Truth 16.27 Sash Lock. Sometimes known as the Truth Entrygard Sash Lock.

3" high x 2-9/16" deep x 1" thick.  We sometimes find the numbers 45208 or 40707 cast into this part.

Left hand sash lock shown in picture.

2-3/8" between screws

Truth 16.16 Sash Lock.

3" x 2-9/16" x 1", with 2-3/8" hole spacing

This sash lock has been discontinued. If you order this part, the 16.27 will be sent as a replacement. According to the factory, the Wi1627 will work as a replacement with any modification.

Used truth keeper # Wi20034

Sweep Lock 7/8"

This Sweep Lock has a hole spacing of 7/8".  The base measures 1/2" x 1-1/2", and is constructed of die cast metal

Roto Casement Sash Lock

Housing measures x 4-3/4" tall by x 3/4" wide. The hole spacing is 3-15/16" center to center. The lifting finger projects out 1-1/8"" with the cut out measuring 11-16" deep by 5/16".

Ives Window Bar Lift 026

Made out of Solid Brass and plated to your selected finish.  Base is 1-1/8" high by 4" wide, with a projection of 1-1/16"

Ives Part # 026B

Ives Sweep Lock07

The Ives Sweep Lock are made of solid brass and plated to your desired finish.   The base is 15/16" x 2-9/16", and the Strike is 5/8" x 2-9/16".  The center to center distance on the screws 1-15/16".

Ives Part # 07

GU Casement Sash Lock

Die Cast Metal and Plastic construction Multi-Point Locking Handle. The base measures 4" tall by 3/4" wide with a 3-5/16" hole spacing.

White only

Casement Sash Lock

Plastic construction Sash Lock.

White only

Window Spring Latch.

This spring latch features 1-3/8" hole spacing. They are used on older transom windows. White Bronze casting, nickel plated and then brushed

Window Spring Latch

This spring latch features 1-3/8" hole spacing. They are used on older transom windows. White Bronze casting, nickel plated and then brushed

Window Spring Latch

Transom window spring loaded window catch. White bronze casting, brushed nickel finish. This Window Spring Catch features a 1-7/16" hole spacing, and a 1/2" lock up dimension.

Truth 17.32 Sweep Latch

This Truth Trimline Cam Lock features a 2-1/16" hole spacing, and the distance from the center of the screw hole and the lock face is 3/8". This sweep lock is also known as a Window Cam Lock, or Double Hung Window Lock.

Truth 16.18 Sash Lock.

Dimensions: 2-3/4" x 2-1/4" x 1"
2" between holes

#45098, 40242, 30386 and 31300 are sometimes found stamped inside the housing

Truth Sash Lock Keeper

Sweep Lock for Aluminum Windows

Made die cast metal, unfinished. Lock measures 1-5/8" x 15/16" x 3/8" projection. Available in left and right versions, the Right Hand version is shown in the picture. This lock is found on aluminum framed windows. Ships with Latch and Nylon Bushing, the screw is not included.

Truth 41269 Right Hand Sash Lock Keeper

Sweep Lock 2-1/4"

Generic sweep latch, used on double hung windows. Also known as a Window Lock, or Double Hung Window Lock. Available in White, Black and Polished Chrome.

Shown in Black

Acorn Sweep Lock 2-1/4"

This sweep latch has a hole spaceing of 2-1/4" between screws. Also known as a Window Lock or Double Hung Window Lock. Acorn Sweep Lock.

White only

Truth 41268 Left Hand Sash Lock Keeper

Sweep Lock 1-1/4" NuPrime

This window sweep lock is made of chrome plated die cast material. The hole spacing on this window lock is 1-1/4".  On this sweep latch we find the numbers D209812, D123,676, and Patent Nos. 3,449,862.  We also find NUPRiME by Season-All

Truth Multi Point Locking System sash lock. The hole spacing on the lock is 3-7/16"

Common numbers found on this lock is 31401 and 31402

Truth 24.89 Multi Point Locking System Sash Lock

31149 is stamped on the Right Hand Sash Lock

31369 is stamped on the Left Hand Sash Lock
