Skylight Hardware

Truth Manual Skylight Operator-Angle Drive Easy to install on wood, metal or vinyl skylights. Gear reduction provides needed lift for sash weights up to 140 lbs. Steel chain is detachable at the sash for easy maintenance.

Truth Manual Skylight Operator- Straight Drive Easy to install on wood, metal or vinyl skylights. Gear reduction provides needed lift for sash weights up to 140 lbs. Steel chain is detachable at the sash for easy maintenance.

Truth 40097 4" handle extension. Great for use with blinds.

11/32" spline

Truth 40096 2" Handle Extension. This is a great product get clearance from a window sill, or to go thru a wooden blind.

Truth part # 40096

Truth Universal With Pole Hook 30325

Use to convert elevated windows and skylights for use with the Pole Wi10638

Truth part # 30325

Truth Manual Skylight Operator Replacement Chain

Chain is 14" overall length

Common numbers found on chain are 30955, 30821, 30658, and 40470

Truth Part # 11537

Truth Telescoping Pole

Telescoping Pole with Hex Ball or Hook Drive
Rigid anodized aluminum poles feature free-turning ABS hand grips.
6 foot pole extends to 10 feet.

Truth Part # 10637 Hex Drive
Truth Part # 10638 Hook Drive

Truth Telescoping Pole Hex Bar Only

Replacement Hex Ball Drive for the Truth Telescoping Pole Crank.  Hex Ball measures 11/16", overall length is 1-15/16" including female insert that fits into pole.  The insert spline is 11/32" with a 1/2" diameter.

Truth Part # 30957

Truth Telescoping Pole Hook Only

Replacement Pole Hook Drive for the Wi10637 for the Truth Telescoping Pole Crank.  The Hook Adapter measures 1" wide, overall length is 2-3/8" including female insert that fits into pole.  The insert spline is 11/32" with a 1/2" diameter.

Truth Part # 10453

Truth Insert

Hex one end and spline on opposite

Truth Universal 30326

Female hex on one end, with the Truth female 11/32" spline.

Truth Manual Skylight Sprocket Gear

The hex measures 3/4", and made of 1/8" cadmium plated steel. This Gear is what pushes the chain.

Truth Part # 30654

Truth Manual Skylight Operator Gear

The gear measures 1-1/16" diameter by 15/16" tall. The hex end is 3/4".

Truth Part # 30742
